Rode M5 vs AKG P170 Microphone Review: Which is the Best Microphone?

Rode M5 and AKG P170 have been among the finest pencil microphones that are largely being used all around the world for recording quality sound.

If you are unsure between Rode M5 and AKG P170, two of the most common handheld microphones at almost the same price, then I made it easy for you with this review of the Rode M5 vs AKG P170 microphone.

Here is a detailed comparison review of the two best options if you’re looking to buy one of them.

Rode M5 Microphone Review

Rode M5 Microphone is a compact pencil microphone that comes at a very reasonable price for the features that it has to offer for the user. I found the sounding to be very clear from Rode M5 in a studio as well as on the stage. This is a very much suitable microphone for drum overheads, and it’s also good for recording high-hats.
Sale
Rode M5-MP Matched Pair Cardioid Condenser Microphones
  • Compact 1/2 inch cardioid condenser microphone with low noise and a full...
  • Matched pair has been carefully selected to ensure a variation of no more than...
  • A premium foiled certificate is supplied to verify the authenticity of the pair
  • Finished with RODE's proprietary ceramic coating which offers a sleek matt black...
  • Supplied with WS5 windshields and RM5 stand mounts

Features of Rode M5

This condenser mic from Rode has a cardioid polar pattern, with a frequency response of 20Hz to 20kHz. It is a good microphone that can record any theatre audio, studio music and it’s also best for recording in the home too.

Having a beautiful matte black metal body construction from Rode, this mic has transformerless circuitry for low noise operation. As a small diaphragm condenser mic, you can record acoustic instruments, choirs, drum overheads, etc.

The body of M5 is in beautiful design, and it has WS5 windshields and RM5 stand mounts that help to ensure good and high-quality sounds.

Technical Specifications of Rode M5 Microphone

MicrophoneRode M5 Microphone
TypeCondenser Microphone
Acoustic PrinciplePressure Gradient
Active ElectronicsJFET impedance converter with bipolar output buffer
Polar PatternCardioid (Unidirectional)
Frequency Range20Hz to 20kHz
Output Impedance200 ohms
Equivalent Noise19 dBA SPL
Maximum Output Level+13.5 dBu
Sensitivity-34 dB re 1V/Pa
Dynamic Range121 dB SPL
Maximum SPL140 dB SPL
Signal to noise Ratio75 dBA SPL
Power Requirement24V or 48V phantom power
Output Connection3 pin XLR
Weight80 g
Buy OnAmazon

Pros and Cons of Rode M5 Microphone

Pros
  • All-metal body ceramic coat
  • Super Lightweight
  • Ultra-low noise recording
  • State-of-the-art surface-mount electronics
  • RM5 Stand mount and WS5 windshields
Cons
  • The capsule on this mic is not replaceable
  • No plastic storage pouch or box included
  • It can sound thin and bright
  • No high-pass switch

Check Price on Amazon

AKG P170 Microphone Review

The AKG P170 is another pencil mic as a small-diaphragm condenser microphone having a great quality performance and reliability. AKG P170 works really well with everything from drum overheads to recording acoustic instruments, etc. This is also a reasonably priced microphone that is offering a quality recording of audio and music.

AKG PERCEPTION 170 Professional Instrumental , 7.40 x 3.50 x 11.30 inches, Sliver Blue - 3101H00410
  • Rugged all-metal body and robust design withstands tough day-to-day use
  • Switchable attenuation pad for high SPL applications up to 155 dB SPL
  • Heavy-duty, roadworthy, all-metal construction
  • Country of Origin: China

Features of AKG P170

Having a cardioid polar pattern, this mic has a 20dB pad that helps to record incredibly clear sound with accurate capturing. You get distortion-free recording with its 20db switchable pad. It has a frequency range of 20Hz to 20kHz. This mic can handle a good sound pressure level at 155db. It has a lightweight 0.5″ gold-sputtered diaphragm.

This is also a metal body mic with durable construction, and it’s very good for the rejection of RF interference. This mic is built to resist any high temperatures and weather conditions like humidity making it a very strong and usable mic under any conditions. It has a good rugged body and sturdy front grille that protects it from the rigors of day-to-day use.

Technical Specifications of AKG P170 Microphone

MicrophoneAKG P170 Microphone
TypeCondenser
Mono/StereoMono
Polar PatternCardioid (Unidirectional)
Diaphragm Size0.5″ (12.7mm)
Frequency Response20Hz to 20kHz
Max SPL135dB (155dB w/Pad)
Output Impedance200 ohms
Signal to Noise Ratio75dB
Self Noise19dB
Sensitivity15 mV/Pa
Pads-20 dB
ConnectorXLR
Weight130 g
Buy OnAmazon

Pros and Cons of AKG P170 Microphone

Pros
  • Built to resist high temperatures and humidity
  • Professional small-diaphragm, condenser cardioid microphone
  • Pressure-Gradient design
  • Switchable 20 dB pad
  • Heavy-duty, an all-metal construction body
  • Switchable 20dB pre-attenuation pad
  • The sturdy front grille protects it from tough handling
Cons
  • According to a customer review, the only problem with this mic is that the clips seem fragile

Check Price on Amazon

Rode M5 vs AKG P170

As I have mentioned everything about both of these mics, now it’s time for a comparison between their output and performance.

The Rode M5 is a more versatile option in terms of power as it can work with either +24V or +48V phantom power, whereas the AKG P170 cannot.

Both of these pencil mics are cardioid and capture sound signals from the front direction and eliminate any signals from the sides and from the back. This makes both of them equally good options for musical recordings as they are very well resistant to environmental noise.

Rode M5 has a good maximum SPL handling of 140 dB, and this makes it a good mic for handling most instruments and vocals.

On the other hand, AKG P170 has a maximum SPL of 135 dB, but it has the advantage of a –20dB switchable pre-attenuation pad that helps it to handle sounds as loud as 155 dB. Hence, it makes it a better option as compared to Rode M5 when you need to handle a very loud vocal or instrument.

Both the Rode M5 and AKG P170 have almost the same sound quality because they have a similar frequency response range and low self-noise levels. These mics can work very well to capture lows, mids, and highs with accuracy.

Talking about the sensitivity, I found that Rode M5 does have a slightly higher sensitivity as compared to AKG P170, but this also means that it is more prone to noise and another sound. AKG P170 has a lower sensitivity than Rode M5, but the performance is still very good, so both of these mics have their own features, but both of them are very good options to consider.

Conclusion

This was a detailed review of the comparison between the Rode M5 mic vs AKG P170 mic. I shared all the info related to both of these mics, including their polar patterns, frequency response, and their sound quality. Considering their design and built quality, both of these pencil microphones are a great option to choose from as they don’t have much of a difference.

If you want my personal opinion then I will suggest you go with Rode M5 Microphone being a more standard option in terms of versatility. Anyway, both the microphones are very close enough similar. You won’t regret getting anyone for you. Do let me know which one you are going to pick.

I hope this review is helpful for you in order to remove your confusion between selecting anyone of these so that you can decide which mic you would actually prefer after reviewing this info. If you liked this microphone review, please leave a response in the section below. Until then, check out my other articles:
